MTE RL-00402

MTE RL-00402 Line/Load Reactor, 208 to 690 V AC, 4 A, 1/2 to 3 hp, 1/4 to 0.33 hp, 6.5 mH, 2, 3 and 5 % Impedance, 4 in H x 4.2 in W

  • Manufacturers: MTE Corporation
  • MFR Part #: RL-00402
  • Revere Part #: 94044
  • UNSPSC: 39121015
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading Branch Available

MTE's RL line/load reactors are best-in-class power quality units with a long history of proven performance. Rugged and robust, they are unequaled in absorbing power line disturbances that can damage or shut down variable frequency drives (VFDs) and other sensitive equipment. They work on both the line side and load side, without derating, to give you an easy solution that reduces nuisance tripping, reduces harmonic distortion and minimizes long lead effects. Improved power quality, enhanced productivity and complete peace of mind are easy with RL line/load reactors.

MTE Line/Load Reactor, Series: RL Series, 208 to 690 V AC, 4 A, 1/2 to 3 hp, 1/4 to 0.33 hp, 1 or 3 ph, 6.5 mH Inductance, 2, 3 and 5 % Impedance, 4 in Height, 4.2 in Width, 2.6 in Depth, Open Enclosure, Surface Mounting

Amperage Rating : 4 A
Depth : 2.6 in
Enclosure Type : Open
Height : 4 in
Horsepower : 1/2 to 3 hp, 1/4 to 0.33 hp
Impedance : 2, 3 and 5 %
Inductance : 6.5 mH
Mounting Type : Surface
Phase : 1 or 3
Series : RL Series
Voltage Rating : 208 to 690 V AC
Width : 4.2 in
  • pdf Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/MTE_RL_00101_Catalog.pdf
  • pdf Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/MTE_RL_00101_Manual.pdf
  • pdf Line Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/MTE_RL_00402_Line_Drawing.pdf
  • link VIDEO LINK https://youtu.be/VaRA_bngkTs
