Federal Signal LP22LED-090-240R

Federal Signal StreamLine® LP22LED-090-240R Low Profile Multi-Pattern Beacon, 90 to 240 V AC, LED Lamp, Surface Mount, Red, CE Certified, cUL Listed, UL Listed

  • Manufacturers: Federal Signal
  • MFR Part #: LP22LED-090-240R
  • Revere Part #: 659458
  • UPC: 782979235835
  • UNSPSC: 39111706
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading Branch Available

Model LP22LED is a unique, multi-pattern LED light ideal for a variety of industrial applications requiring low profile signaling. The unit can be flush mounted or mounted on a 1/2 in NPT pipe with the integrated pipe mount. The enclosure consists of a polycarbonate dome in five colors (amber, blue, clear, green and red) and is rated NEMA 4X. The LP22LED has four flash patterns (steady light, single flash, double flash and triple flash) selectable via dip switch.

Federal Signal StreamLine® Beacon, Low Profile Multi-Pattern, Series: LP22LED, 90 to 240 V AC, 40 mA, Cylindrical Shape, LED Lamp, Red, Double/Single/Steady/Triple Flash, 90/120/140 fpm Flash, 50000 hr Average Life, Specifications Met: CE Certified, cUL Listed, UL Listed, Surface Mounting, NEMA 4X/IP65 NEMA Rating, -22 to 122 deg F, Polycarbonate Housing Material, 2.99 in W x 2.99 in D x 3.385 in H Dimensions

  • pdf Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Federal_Signal_LP22LED_012_024A_Manual.pdf
  • pdf Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_1520545253976.pdf
  • pdf Warranty Information https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_7efe597170cfafef0ac1281e9c280a87c26b03787e7065fb8d691fd6eb241015.pdf
  • pdf Line Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_affa216269130a5976665fe7ca535c286ccb406c6291f49478eefdbe0826816d.pdf
