Panduit® Pan-Lug™ LCA4/0-12-X 1-Hole Compression Lug Connector With Inspection Window, 4/0 AWG Stranded Copper Conductor, Die Code: P54, 1/2 in Stud, Copper

  • Manufacturers: Panduit
  • MFR Part #: LCA4/0-12-X
  • Revere Part #: 98398
  • UPC: 074983900411
  • UNSPSC: 39121405
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading Branch Available

Panduit® Pan-Lug™ Compression Lug Connector, 1-Hole, Series: LCA, Stranded Copper Conductor, 4/0 AWG Conductor, Die Code: P54, 35 kV, 1/2 in Stud, Straight Tongue, 1.06 in W x 0.14 in THK Tongue, 2.68 in Overall Length, Standard/Inspection Window Barrel, 0.57 in ID x 0.71 in OD x 1.19 in L Barrel, Specifications: 1-1/4 in L Wire Strip, Tin Plated, 90 deg C, 1-1/4 in Mounting Hole, Copper, Purple

Barrel Size : 0.57 in ID x 0.71 in OD x 1.19 in L
Barrel Type : Standard/Inspection Window
Color : Purple
Conductor Size : 4/0 AWG
Conductor Type : Stranded Copper
Die Code : P54
Material : Copper
Mounting Hole Size : 1-1/4 in
Overall Length : 2.68 in
Series : LCA
Specifications : 1-1/4 in L Wire Strip, Tin Plated
Stud Size : 1/2 in
Temperature Rating : 90 deg C
Tongue Size : 1.06 in W x 0.14 in THK
Tongue Type : Straight
Type : 1-Hole
Voltage Rating : 35 kV
