Panduit® LCDX250-12-X

Panduit® Pan-Lug™ LCDX250-12-X 2-Hole Compression Connector Lug, 250 kcmil, 262.6 kcmil Flexible Copper Conductor, Die Code: P62, 42.767 in Stud, Tin Plated Copper

  • Manufacturers: Panduit
  • MFR Part #: LCDX250-12-X
  • Revere Part #: 1089639
  • UPC: 074983423996
  • UNSPSC: 39121405
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading Branch Available

Panduit® Pan-Lug™ Compression Connector Lug, 2-Hole, Series: LCDX, Flexible Copper Conductor, 250 kcmil, 262.6 kcmil Conductor, Die Code: P62, 35 kV, 42.767 in Stud, Straight Tongue, 1.28 in W x 0.17 in THK Tongue, 4.56 in Overall Length, Standard Barrel, 0.7 in ID x 0.7 in OD x 1.03 in L Barrel, 2.9375 in L Wire Strip, 1-3/4 in Stud Hole Spacing, 90 deg C, 1.06 in Mounting Hole, Tin Plated Copper, Yellow

Barrel Size : 0.7 in ID x 0.7 in OD x 1.03 in L
Barrel Type : Standard
Color : Yellow
Conductor Size : 250 kcmil, 262.6 kcmil
Conductor Type : Flexible Copper
Die Code : P62
Material : Tin Plated Copper
Mounting Hole Size : 1.06 in
Overall Length : 4.56 in
Series : LCDX
Specifications : 2.9375 in L Wire Strip, 1-3/4 in Stud Hole Spacing
Stud Size : 42.767 in
Temperature Rating : 90 deg C
Tongue Size : 1.28 in W x 0.17 in THK
Tongue Type : Straight
Type : 2-Hole
Voltage Rating : 35 kV
  • pdf Technical Bulletin https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Panduit_LCC2-14BW-Q_Technical_Bulletin.pdf
  • pdf Full Engineering Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Panduit_LCDX250-12-X_Full_Engineering_Drawing.pdf
  • pdf Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Panduit_LCDX8-14A-L_Installation_Manual.pdf
  • video VIDEO LINK https://www.panduit.com/content/dam/panduit/en/products/media/7/77/277/5277/110185277.mp4
