BURNDY® YA342LN
BURNDY® HYLUG™ YA342LN YA-2LN 2-Hole Compression Lug With Inspection Window, 500 kcmil Stranded Copper Conductor, Die Code: 20/299, 1/2 in Stud, Copper
- Manufacturers: Hubbell
- MFR Part #: YA342LN
- Revere Part #: 155144
- UPC: 781810505953
- UNSPSC: 39121405
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
-
Price: Login For Price
500 kcmil CU, Two Hole, 1/2 Stud Size, 1-3/4 Hole Spacing, Standard Barrel, Inspection Window, Internal Chamfer, Tin Plated, UL/CSA, 90°C, Up to 35kV, Brown Color Code, 20 or 299 Die Index.
BURNDY® HYLUG™ Compression Lug, 2-Hole, Series: YA-2LN, Stranded Copper Conductor, 500 kcmil Conductor, Die Code: 20/299, 600 V AC to 35 kV, 1/2 in Stud, Standard/Straight Tongue, 1.55 in W x 0.23 in THK Tongue, 5.06 in Overall Length, Chamfered/Short/Skived/Standard Barrel, 1.27 in L Barrel, 1-3/4 in Stud Hole Spacing, 1-7/16 in L Wire Strip, Tin Plated, 90 deg C, Copper, Brown
| Barrel Size | : | 1.27 in L |
| Barrel Style | : | Chamfered/Short/Skived/Standard |
| Barrel Type | : | Chamfered/Short/Skived/Standard |
| Color | : | Brown |
| Conductor Size | : | 500 kcmil |
| Conductor Type | : | Stranded Copper |
| Die Code | : | 20/299 |
| Material | : | Copper |
| Overall Length | : | 5.06 in |
| Series | : | YA-2LN |
| Specifications | : | 1-3/4 in Stud Hole Spacing, 1-7/16 in L Wire Strip, Tin Plated |
| Stud Size | : | 1/2 in |
| Temperature Rating | : | 90 deg C |
| Tongue Size | : | 1.55 in W x 0.23 in THK |
| Tongue Style | : | Standard/Straight |
| Tongue Type | : | Standard/Straight |
| Type | : | 2-Hole |
| Voltage Rating | : | 600 V AC to 35 kV |
