BURNDY® YA252LN
BURNDY® HYLUG™ YA252LN YA-2LN 2-Hole Compression Lug With Inspection Window, 1/0 AWG Stranded Copper Conductor, Die Code: 12, 1/2 in Stud, Copper
- Manufacturers: Hubbell
- MFR Part #: YA252LN
- Revere Part #: 397068
- UPC: 781810502273
- UNSPSC: 39121405
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
-
Price: Login For Price
1/0 AWG CU, Two Hole, 1/2 Stud Size, 1-3/4 Hole Spacing, Standard Barrel, Inspection Window, Internal Chamfer, Tin Plated, UL/CSA, 90°C, Up to 35kV, Pinnk Color Code, 12 or 348 Die Index.
BURNDY® HYLUG™ Compression Lug, 2-Hole, Series: YA-2LN, Stranded Copper Conductor, 1/0 AWG Conductor, Die Code: 12, 600 V AC to 35 kV, 1/2 in Stud, Standard/Straight Tongue, 0.83 in W x 0.11 in THK Tongue, 4.29 in Overall Length, Chamfered/Short/Skived/Standard Barrel, 0.88 in L Barrel, 1-3/4 in Stud Hole Spacing, 15/16 in L Wire Strip, Tin Plated, 90 deg C, Copper, Pink
| Barrel Size | : | 0.88 in L |
| Barrel Style | : | Chamfered/Short/Skived/Standard |
| Barrel Type | : | Chamfered/Short/Skived/Standard |
| Color | : | Pink |
| Conductor Size | : | 1/0 AWG |
| Conductor Type | : | Stranded Copper |
| Die Code | : | 12 |
| Material | : | Copper |
| Overall Length | : | 4.29 in |
| Series | : | YA-2LN |
| Specifications | : | 1-3/4 in Stud Hole Spacing, 15/16 in L Wire Strip, Tin Plated |
| Stud Size | : | 1/2 in |
| Temperature Rating | : | 90 deg C |
| Tongue Size | : | 0.83 in W x 0.11 in THK |
| Tongue Style | : | Standard/Straight |
| Tongue Type | : | Standard/Straight |
| Type | : | 2-Hole |
| Voltage Rating | : | 600 V AC to 35 kV |
