Nsi IPCS5040
NSI EASY-TAP IPCS5040 Dual Rated Piercing Insulation Connector, 2/0 AWG to 500 kcmil Aluminum/Copper Conductor, Fiber Reinforced Thermal Plastic
- Manufacturers: NSi Industries
- MFR Part #: IPCS5040
- Revere Part #: 546345
- UPC: 662381082688
- UNSPSC: 39121428
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
-
Price: Login For Price
Insulation Piercing Connector 500 MCM - 2/0 AWG Insulation piercing connectors are made for use with copper-copper, copper to aluminum and aluminum to aluminum applications. They are safe to use and are completely insulated, no need to strip wire. They can be installed on energized conductors with no contact at any point. No spacer required between connections. Exclusive "turbo spacer" keeps tap side open while main conductor is being tightened. Watertight and corrosion-free.
NSI EASY-TAP Piercing Insulation Connector, Dual Rated, Series: IPCS, Aluminum/Copper Conductor, 2/0 AWG to 500 kcmil Conductor, 600 V AC, 405 A Copper, 315 A Aluminum, 90 deg C, Clamping Mount, Fiber Reinforced Thermal Plastic, Black, 3.9 in L x 3 in W x 4.5 in H
| Color | : | Black |
| Conductor Size | : | 2/0 AWG to 500 kcmil |
| Conductor Type | : | Aluminum/Copper |
| Dimensions | : | 3.9 in L x 3 in W x 4.5 in H |
| Material | : | Fiber Reinforced Thermal Plastic |
| Mounting Type | : | Clamping |
| Series | : | IPCS |
| Specifications | : | 405 A Copper, 315 A Aluminum |
| Temperature Rating | : | 90 deg C |
| Type | : | Dual Rated |
| Voltage Rating | : | 600 V AC |
Specification Sheet
