BURNDY® YAV26L

BURNDY® HYLUG™ YAV26L YAV-L 1-Hole Heavy Duty Uninsulated Compression Lug With Inspection Window, 2/0 AWG Stranded Copper Conductor, Die Code: 44, 3/8 in Stud, Electrolytic Copper

  • Manufacturers: Hubbell
  • MFR Part #: YAV26L
  • Revere Part #: 45897
  • UPC: 781810025697
  • UNSPSC: 39121405
  • Min. Order Qty: 1
  • Qty. Interval: 100
  • Availability: loading Branch Available

Copper Compression Lug, 1 Hole w/ Inspection Window, AN-2/0 Flex, 3/8" Stud, Short Barrel, Tin Plated.

BURNDY® HYLUG™ Compression Lug, 1-Hole Heavy Duty Uninsulated, Series: YAV-L, Stranded Copper Conductor, 2/0 AWG Conductor, Die Code: 44, 600 V AC, 3/8 in Stud, Ring Straight Tongue, 0.93 in OD Tongue, 2.31 in Overall Length, Short Barrel, 0.782 in L Barrel, 13/16 in L Wire Strip, Electrolytic Copper
