BURNDY® YA38L2NTCFX
BURNDY® HYLUG™ YA38L2NTCFX YA-L-2TC-FX 2-Hole Compression Lug With Inspection Window, 535.3 kcmil Flexible Copper Conductor, Die Code: L99, 1/2 in Stud, Copper
- Manufacturers: Hubbell
- MFR Part #: YA38L2NTCFX
- Revere Part #: 45805
- UPC: 781810521724
- UNSPSC: 39121405
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
-
Price: Login For Price
500 kcmil H,I,K / 550 kcmil G,H,I,535 DLO CU, Two Hole, 1/2 Stud Size, 1-3/4 Hole Spacing, Standard Barrel, Inspection Window, Internal Chamfer, Tin Plated, UL/CSA, 90°C, Up to 35kV, Pink Color Code, L99 Die Index.
BURNDY® HYLUG™ Compression Lug, 2-Hole, Series: YA-L-2TC-FX, Flexible Copper Conductor, 535.3 kcmil Conductor, Die Code: L99, 600 V AC to 35 kV, 1/2 in Stud, Standard/Straight Tongue, 1.84 in W x 0.27 in THK Tongue, 5.35 in Overall Length, Chamfered/Short/Skived/Standard Barrel, 1.45 in L Barrel, 1-1/2 in L Wire Strip, 1-3/4 in Stud Hole Spacing, Tin Plated, 90 deg C, Copper, Pink
| Barrel Size | : | 1.45 in L |
| Barrel Style | : | Chamfered/Short/Skived/Standard |
| Barrel Type | : | Chamfered/Short/Skived/Standard |
| Color | : | Pink |
| Conductor Size | : | 535.3 kcmil |
| Conductor Type | : | Flexible Copper |
| Die Code | : | L99 |
| Material | : | Copper |
| Overall Length | : | 5.35 in |
| Series | : | YA-L-2TC-FX |
| Specifications | : | 1-1/2 in L Wire Strip, 1-3/4 in Stud Hole Spacing, Tin Plated |
| Stud Size | : | 1/2 in |
| Temperature Rating | : | 90 deg C |
| Tongue Size | : | 1.84 in W x 0.27 in THK |
| Tongue Style | : | Standard/Straight |
| Tongue Type | : | Standard/Straight |
| Type | : | 2-Hole |
| Voltage Rating | : | 600 V AC to 35 kV |
