BURNDY® YGHP29C26
BURNDY® HYTAP™ YGHP29C26 YGH Type YGHP Mechanical Compression Ground Rod Connector, Figure 6 Shape, 1/0 AWG to 250 kcmil Main/Run, 1/0 to 2/0 AWG Tap
- Manufacturers: Hubbell
- MFR Part #: YGHP29C26
- Revere Part #: 374726
- UPC: 781810220931
- UNSPSC: 39121427
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
-
Price: Login For Price
Cu Compression Ground Rod Connector, 1/0 Str - 2/0 str, 1/2" - 5/8" Rod Dia.
BURNDY® HYTAP™ YGHP29C26, Compression Ground Rod Connector, Type YGHP Mechanical, Series: YGH, Figure 6 Shape, 1/0 AWG to 250 kcmil Main/Run, 1/0 to 2/0 AWG Tap, Stranded Copper Conductor, Specifications: 1/2 to 5/8 in Rod, 997 Element A Die Index, Unplated, 3/4 in L Dimensions
| Conductor Type | : | Stranded Copper |
| Dimensions | : | 3/4 in L |
| Finish | : | Unplated |
| Main/Run Size | : | 1/0 AWG to 250 kcmil |
| Material | : | Copper |
| Series | : | YGH |
| Shape | : | Figure 6 |
| Specifications | : | 1/2 to 5/8 in Rod, 997 Element A Die Index |
| Tap Size | : | 1/0 to 2/0 AWG |
| Type | : | Type YGHP Mechanical |
Line Drawing
