BURNDY® YA282N

BURNDY® HYLUG™ YA282N YA-N 2-Hole Compression Lug, 4/0 AWG, Die Code: 15, 1/2 in Stud, Tin Plated Copper

  • Manufacturers: Hubbell
  • MFR Part #: YA282N
  • Revere Part #: 45738
  • UPC: 781810503652
  • UNSPSC: 39121405
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading Branch Available

4/0 AWG CU, Two Hole, 1/2 Stud Size, 1-3/4 Hole Spacing, Long Barrel Internal Chamfer, Tin Plated, UL/CSA, 90脗掳C, Up to 35kV, Purple Color Code, 15 Die Index.

BURNDY® HYLUG™ YA282N, Compression Lug, 2-Hole, Series: YA-N, 4/0 AWG Conductor, Die Code: 15, 600 to 35000 V AC, 1/2 in Stud, Straight Tongue, 1.02 in W x 0.14 in THK Tongue, 5.17 in Overall Length, Chamfered/Long Barrel, 1.62 in L Barrel, Specifications: 1-11/16 in L Wire Strip, 90 deg C, 1-3/4 in Mounting Hole, Tin Plated Copper, Purple

  • pdf Full Engineering Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YA282N_Full_Engineering_Drawing.pdf
  • pdf Line Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YA282N_Line_Drawing_CA.pdf
  • pdf Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YA282N_Specification_Sheet.pdf
  • pdf Owners/User Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YA282N_User_Manual.pdf
  • link VIDEO LINK https://players.brightcove.net/2519281010001/S1rfC16yx_default/index.html?videoId=6319929968112
