Panduit® LCD4/0-12-X

Panduit® Pan-Lug™ LCD4/0-12-X 2-Hole Compression Lug, 4/0 AWG Copper Conductor, Die Code: P54, 42.767 in Stud, Copper

  • Manufacturers: Panduit
  • MFR Part #: LCD4/0-12-X
  • Revere Part #: 230738
  • UPC: 074983900961
  • UNSPSC: 39121405
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading Branch Available

Panduit® Pan-Lug™ Compression Lug, 2-Hole, Series: LCD, Copper Conductor, 4/0 AWG Conductor, Die Code: P54, 35 kV, 42.767 in Stud, Standard/Straight Tongue, 1.06 in W x 0.14 in THK Tongue, 4.58 in Overall Length, Standard/Inspection Window Barrel, 0.57 in ID x 0.71 in OD x 1.19 in L Barrel, Specifications: 1-1/4 in L Wire Strip, 1-3/4 in Stud Hole Spacing, Tin Plated Finish, 90 deg C, 1-1/4 in Mounting Hole, Copper, Purple

  • pdf Technical Bulletin https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Panduit_LCC8-10AW-L_Technical_Bulletin.pdf
  • pdf Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Panduit_LCD4-10A-L_Installation_Manual.pdf
  • pdf Full Engineering Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Panduit_LCD4_0-12-X_Full_Engineering_Drawing.pdf
  • video VIDEO LINK https://www.panduit.com/content/dam/panduit/en/products/media/7/77/277/5277/110185277.mp4
