Panduit® LCAN3/0-38-X

Panduit® Pan-Lug™ LCAN3/0-38-X 1-Hole Compression Lug Connector With Inspection Window, 3/0 AWG Stranded Copper Conductor, Die Code: P50, 3/8 in Stud, Tin Plated Copper

  • Manufacturers: Panduit
  • MFR Part #: LCAN3/0-38-X
  • Revere Part #: 206876
  • UPC: 074983603381
  • UNSPSC: 39121405
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading Branch Available

Panduit® Pan-Lug™ Compression Lug Connector, 1-Hole, Series: LCAN, Stranded Copper Conductor, 3/0 AWG Conductor, Die Code: P50, 35 kV, 3/8 in Stud, Narrow/Straight Tongue, 0.64 in W x 0.16 in THK Tongue, 2.36 in Overall Length, Standard/Inspection Window Barrel, 0.51 in ID x 0.64 in OD x 1.14 in L Barrel, Specifications: 1-3/16 in L Wire Strip, Tin Plated, 90 deg C, 1-3/16 in Mounting Hole, Tin Plated Copper, Orange

Barrel Size : 0.51 in ID x 0.64 in OD x 1.14 in L
Barrel Type : Standard/Inspection Window
Color : Orange
Conductor Size : 3/0 AWG
Conductor Type : Stranded Copper
Die Code : P50
Material : Tin Plated Copper
Mounting Hole Size : 1-3/16 in
Overall Length : 2.36 in
Series : LCAN
Specifications : 1-3/16 in L Wire Strip, Tin Plated
Stud Size : 3/8 in
Temperature Rating : 90 deg C
Tongue Size : 0.64 in W x 0.16 in THK
Tongue Type : Narrow/Straight
Type : 1-Hole
Voltage Rating : 35 kV
