BURNDY® C11N

BURNDY® C11N Grounding Clamp, 10 to 3/0 AWG Conductor, Cast Bronze

  • Manufacturer: Hubbell
  • MFR Part #: C11N
  • Revere Part #: 45329
  • UPC: 781810142288
  • UNSPSC: 39121408
  • Min Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading Branch Available

Cast Bronze Ground Clamp, Cable to Water Pipe or Copper Tube, 10 - 2 AWG, 1/2"- 1" Water Pipe, pipe clamp:50 in-lb.

BURNDY® Grounding Clamp, 3/8 to 1 in Pipe, 0.84 to 1.315 in Outside Dia, Copper/Stranded Conductor, 10 to 3/0 AWG Conductor, Cable Parallel to Pipe, Screw Installation, Cast Bronze, Zinc Plated, 2.25 in L x 0.63 in W x 1.81 in H

Conductor Size : 10 to 3/0 AWG
Conductor Type : Copper/Stranded
Connection Type : Cable Parallel to Pipe
Dimensions : 2.25 in L x 0.63 in W x 1.81 in H
Finish : Zinc Plated
Installation : Screw
Material : Cast Bronze
Outside Diameter : 0.84 to 1.315 in
Pipe Size : 3/8 to 1 in
  • No armored cable
  • No ground strap
  • pdf Full Engineering Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_C11N_Full_Engineering_Drawing.pdf
  • pdf Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_C11N_Specification_Sheet.pdf
  • pdf Owners/User Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_C11N_User_Manual.pdf
