BURNDY® YAV26LTC12FX

BURNDY® HYLUG™ YAV26LTC12FX YAV-L-FX 1-Hole Compression Lug With Inspection Window, 2/0 AWG Flexible/Stranded Copper Conductor, Die Code: 13, 1/2 in Stud, Copper

  • Manufacturers: Hubbell
  • MFR Part #: YAV26LTC12FX
  • Revere Part #: 535768
  • UPC: 781810021972
  • UNSPSC: 39121405
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading Branch Available

2/0 Flex G,H,I,K,M,DLO, 2/0 AWG CU, One Hole, 1/2 Stud Size, Standard Barrel, Inspection Window Internal Chamfer, Tin Plated, UL/CSA, 90°C, Up to 35kV, Black Color Code, 13 Die Index.

BURNDY® HYLUG™ Compression Lug, 1-Hole, Series: YAV-L-FX, Flexible/Stranded Copper Conductor, 2/0 AWG Conductor, Die Code: 13, 600 V AC to 35 kV, 1/2 in Stud, Standard/Straight Tongue, 0.93 in W x 0.13 in THK Tongue, 2.36 in Overall Length, Chamfered/Short/Standard Barrel, 0.81 in L Barrel, 13/16 in L Wire Strip, Tin Plated, 90 deg C, Copper, Black

  • pdf Full Engineering Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YA34LTC58FX_Full_Engineering_Drawing.pdf
  • pdf Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YA44A1_Installation_Manual.pdf
  • pdf Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YAV26LTC12FX_Specification_Sheet.pdf
  • pdf Owners/User Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YAV26LTC12FX_User_Manual.pdf
  • link VIDEO LINK https://players.brightcove.net/2519281010001/S1rfC16yx_default/index.html?videoId=6319929968112
