BURNDY® YA312LN
BURNDY® HYLUG™ YA312LN YA-2LN 2-Hole Compression Lug With Inspection Window, 350 kcmil Stranded Copper Conductor, Die Code: 18/324, 1/2 in Stud, Copper
- Manufacturers: Hubbell
- MFR Part #: YA312LN
- Revere Part #: 195424
- UPC: 781810505076
- UNSPSC: 39121405
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
-
Price: Login For Price
350 kcmil CU, Two Hole, 1/2 Stud Size, 1-3/4 Hole Spacing, Standard Barrel, Inspection Window, Internal Chamfer, Tin Plated, UL/CSA, 90°C, Up to 35kV, Red Color Code, 18 or 324 Die Index.
BURNDY® HYLUG™ Compression Lug, 2-Hole, Series: YA-2LN, Stranded Copper Conductor, 350 kcmil Conductor, Die Code: 18/324, 600 V AC to 35 kV, 1/2 in Stud, Standard/Straight Tongue, 1.29 in W x 0.18 in THK Tongue, 4.7 in Overall Length, Chamfered/Short/Standard Barrel, 1.06 in L Barrel, 1-3/16 in L Wire Strip, 1-3/4 in Stud Hole Spacing, Tin Plated, 90 deg C, Copper, Red
| Barrel Size | : | 1.06 in L |
| Barrel Style | : | Chamfered/Standard/Short |
| Barrel Type | : | Chamfered/Short/Standard |
| Color | : | Red |
| Conductor Size | : | 350 kcmil |
| Conductor Type | : | Stranded Copper |
| Die Code | : | 18/324 |
| Material | : | Copper |
| Overall Length | : | 4.7 in |
| Series | : | YA-2LN |
| Specifications | : | 1-3/16 in L Wire Strip, 1-3/4 in Stud Hole Spacing, Tin Plated |
| Stud Size | : | 1/2 in |
| Temperature Rating | : | 90 deg C |
| Tongue Size | : | 1.29 in W x 0.18 in THK |
| Tongue Style | : | Standard/Straight |
| Tongue Type | : | Standard/Straight |
| Type | : | 2-Hole |
| Voltage Rating | : | 600 V AC to 35 kV |
