Panduit® LCD350-12-X

Panduit® Pan-Lug™ LCD350-12-X 2-Hole Compression Lug, 350 kcmil Stranded Copper Conductor, Die Code: P71, 42.767 in Stud, Copper

  • Manufacturers: Panduit
  • MFR Part #: LCD350-12-X
  • Revere Part #: 377014
  • UPC: 074983901029
  • UNSPSC: 39121405
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading Branch Available

Panduit® Pan-Lug™ Compression Lug, 2-Hole, Series: LCD, Stranded Copper Conductor, 350 kcmil Conductor, Die Code: P71, 35 kV, 42.767 in Stud, Standard/Straight Tongue, 1.28 in W x 0.17 in THK Tongue, 4.96 in Overall Length, Standard/Inspection Window Barrel, 0.7 in ID x 0.88 in OD x 1.44 in L Barrel, Specifications: 1-1/2 in L Wire Strip, 1-3/4 in Stud Hole Spacing, Tin Plated Finish, 90 deg C, 1-1/2 in Mounting Hole, Copper, Red

  • pdf Technical Bulletin https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Panduit_LCC8-10AW-L_Technical_Bulletin.pdf
  • pdf Full Engineering Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Panduit_LCD350-12-X_Full_Engineering_Drawing.pdf
  • pdf Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Panduit_LCD4-10A-L_Installation_Manual.pdf
  • video VIDEO LINK https://www.panduit.com/content/dam/panduit/en/products/media/7/77/277/5277/110185277.mp4
