ILSCO® CSWS-250-38

ILSCO® SureCrimp® CSWS-250-38 CSWS 1-Hole Lug Compression Connector Sight Hole With Sight Hole, 1/0 AWG to 250 kcmil Flex Copper Conductor, Die Code: ILD-62, 3/8 in Stud, Tin Plated Copper

  • Manufacturers: ECM Industries
  • MFR Part #: CSWS-250-38
  • Revere Part #: 721488
  • UPC: 783669640731
  • UNSPSC: 39121448
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading Branch Available

ILSCO® SureCrimp® Lug Compression Connector Sight Hole, 1-Hole, Series: CSWS, Flex Copper Conductor, 1/0 AWG to 250 kcmil Conductor, Die Code: ILD-62, 600 to 35 kV V AC, 3/8 in Stud, 0.875 in L x 1.088 in W x 0.157 in THK Tongue, 2.469 in Overall Length, Chamfered/Short/Standard Barrel, 0.593 in ID x 0.75 in OD x 1.063 in L Barrel, 1-1/8 in L Wire Strip, 90 deg C, 0.406 in Mounting Hole, Tin Plated Copper, Yellow, 1.088 in W

Barrel Size : 0.593 in ID x 0.75 in OD x 1.063 in L
Barrel Type : Chamfered/Short/Standard
Color : Yellow
Conductor Size : 1/0 AWG to 250 kcmil
Conductor Type : Flex Copper
Die Code : ILD-62
Dimensions : 1.088 in W
Material : Tin Plated Copper
Mounting Hole Size : 0.406 in
Overall Length : 2.469 in
Series : CSWS
Specifications : 1-1/8 in L Wire Strip
Stud Size : 3/8 in
Temperature Rating : 90 deg C
Tongue Size : 0.875 in L x 1.088 in W x 0.157 in THK
Type : 1-Hole
Voltage Rating : 600 to 35 kV V AC
