BURNDY® YA27LNT38

BURNDY® HYLUG™ YA27LNT38 YA-L-NT 1-Hole Compression Lug, 3/0 AWG Flexible/Stranded Copper Conductor, Die Code: 14, 3/8 in Stud, Copper

  • Manufacturers: Hubbell
  • MFR Part #: YA27LNT38
  • Revere Part #: 602771
  • UPC: 781810018538
  • UNSPSC: 39121405
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading Branch Available

3/0 AWG CU, One Hole, 3/8 Standard Barrel, Inspection Window, Narrow Tongue Internal Chamfer, Tin Plated, UL/CSA, 90°C, Up to 35kV, ORANGE Color Code, 14 Die Index.

BURNDY® HYLUG™ Compression Lug, 1-Hole, Series: YA-L-NT, Flexible/Stranded Copper Conductor, 3/0 AWG Conductor, Die Code: 14, 600 V AC to 35 kV, 3/8 in Stud, Narrow/Standard/Straight Tongue, 0.76 in W x 0.12 in THK Tongue, 2.73 in Overall Length, Chamfered/Narrow/Standard Barrel, 1 in L Barrel, 1-1/16 in L Wire Strip, Electro-Tin Plated, 90 deg C, Copper, Orange

  • pdf Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YA27LNT38_Specification_Sheet.pdf
  • pdf Owners/User Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YA27LNT38_User_Manual.pdf
  • pdf Full Engineering Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YA4CLNT10_Full_Engineering_Drawing.pdf
  • pdf Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YA4CLNT10_Installation_Manual.pdf
  • link VIDEO LINK https://players.brightcove.net/2519281010001/S1rfC16yx_default/index.html?videoId=6319929968112
