BURNDY® YAV28L2NTCFX

BURNDY® HYLUG™ YAV28L2NTCFX YAV-L-2TC-FX 2-Hole Compression Lug With Inspection Window, 4/0 AWG Flexible/Stranded Copper Conductor, Die Code: 15, 1/2 in Stud, Copper

  • Manufacturers: Hubbell
  • MFR Part #: YAV28L2NTCFX
  • Revere Part #: 612183
  • UPC: 781810022085
  • UNSPSC: 39121405
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading Branch Available

4/0 Flex G,H,I,K,M,DLO, 4/0 AWG CU, Two Hole, 1/2 Stud Size, 1-3/4 Hole Spacing, Standard Barrel, Inspection Window, Internal Chamfer, Tin Plated, UL/CSA, 90°C, Up to 35kV, Purple Color Code, 15 Die Index.

BURNDY® HYLUG™ Compression Lug, 2-Hole, Series: YAV-L-2TC-FX, Flexible/Stranded Copper Conductor, 4/0 AWG Conductor, Die Code: 15, 600 V AC to 35 kV, 1/2 in Stud, Standard/Straight Tongue, 1.14 in W x 0.15 in THK Tongue, 4.62 in Overall Length, Chamfered/Short/Skived/Standard Barrel, 1.03 in L Barrel, 1-1/16 in L Wire Strip, 1-3/4 in Stud Hole Spacing, Tin Plated, 90 deg C, Copper, Purple

  • pdf Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YA38L2ENT38FX_Installation_Manual.pdf
  • pdf Full Engineering Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YAV1CL2TC38FX_Full_Engineering_Drawing.pdf
  • pdf Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YAV28L2NTCFX_Specification_Sheet.pdf
  • pdf Owners/User Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YAV28L2NTCFX_User_Manual.pdf
  • link VIDEO LINK https://players.brightcove.net/2519281010001/S1rfC16yx_default/index.html?videoId=6319929968112
