BURNDY® YA29L4

BURNDY® HYLUG™ YA29L4 YA-L 1-Hole Compression Lug With Inspection Window, 250 kcmil Stranded Copper Conductor, Die Code: 16, 3/8 in Stud, Copper

  • Manufacturers: Hubbell
  • MFR Part #: YA29L4
  • Revere Part #: 693838
  • UPC: 781810554524
  • UNSPSC: 39121405
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading Branch Available

250 kcmil CU, One Hole, 3/8 Stud Size, Standard Barrel, Inspection Window, Internal Chamfer, Tin Plated, UL/CSA 90° Up to 35kV, YELLOW Color Code, 16 Die Index.

BURNDY® HYLUG™ Compression Lug, 1-Hole, Series: YA-L, Stranded Copper Conductor, 250 kcmil Conductor, Die Code: 16, 600 V AC to 35 kV, 3/8 in Stud, Standard/Straight Tongue, 1.11 in W x 0.16 in THK Tongue, 2.42 in Overall Length, Internal Chamfer/Skived/Short/Standard Barrel, 0.75 in OD x 1.06 in L Barrel, 0.41 in Stud Hole Spacing, 1-1/8 in L Wire Strip, Tin Plated, 90 deg C, Copper, Yellow

  • pdf Full Engineering Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YA27L2_Full_Engineering_Drawing.pdf
  • pdf Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YA29L4_Specification_Sheet.pdf
  • pdf Owners/User Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YA29L4_User_Manual.pdf
  • pdf Line Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YA31L11_Line_Drawing.pdf
  • pdf Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YA44A1_Installation_Manual.pdf
  • pdf Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YA4CLNT10_Installation_Manual.pdf
  • link VIDEO LINK https://players.brightcove.net/2519281010001/S1rfC16yx_default/index.html?videoId=6319929968112
