BURNDY® YAV28LTC38FX

BURNDY® HYLUG™ YAV28LTC38FX YAV-L-FX 1-Hole Compression Lug With Inspection Window, 4/0 AWG Flexible/Stranded Copper Conductor, Die Code: 15, 3/8 in Stud, Copper

  • Manufacturers: Hubbell
  • MFR Part #: YAV28LTC38FX
  • Revere Part #: 606326
  • UPC: 781810021934
  • UNSPSC: 39121405
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading Branch Available

Copper Compression Lug, 1 Hole w/ Inspection Window, 4/0 Flex, 3/8" Stud, Short Barrel, Tin Plated.

BURNDY® HYLUG™ Compression Lug, 1-Hole, Series: YAV-L-FX, Flexible/Stranded Copper Conductor, 4/0 AWG Conductor, Die Code: 15, 600 V AC to 35 kV, 3/8 in Stud, Standard/Straight Tongue, 1.14 in W x 0.15 in THK Tongue, 2.42 in Overall Length, Chamfered/Short/Standard Barrel, 1.03 in L Barrel, 1-1/16 in L Wire Strip, Tin Plated, 90 deg C, Copper, Purple

  • pdf Full Engineering Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YA34LTC58FX_Full_Engineering_Drawing.pdf
  • pdf Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YAV28LTC38FX_Specification_Sheet.pdf
  • pdf Owners/User Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YAV28LTC38FX_User_Manual.pdf
  • pdf Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_YAV4CLTC12FX_Installation_Manual.pdf
  • link VIDEO LINK https://players.brightcove.net/2519281010001/S1rfC16yx_default/index.html?videoId=6319929968112
