ILSCO® IPC-500-250

ILSCO® KUP-L-Tap® IPC-500-250 Type IPC Dual Rated Insulation Piercing Connector, 250 to 500 kcmil Aluminum/Copper Conductor, 5/8 to 11/16 in, Copper

  • Manufacturers: ECM Industries
  • MFR Part #: IPC-500-250
  • Revere Part #: 679050
  • UPC: 783669532784
  • UNSPSC: 39121408
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading Branch Available

ILSCO® KUP-L-Tap® Insulation Piercing Connector, Type IPC Dual Rated, Aluminum/Copper Conductor, 250 to 500 kcmil Conductor, 5/8 to 11/16 in Bolt, 600 V AC, Specifications: 55 ft-lb Torque, 290 A Copper, 230 A Aluminum, 90 deg C, Copper, Tin Plated, Black, 3-3/4 in H x 2-29/32 in W Dimensions

Bolt Size : 5/8 to 11/16 in
Color : Black
Conductor Size : 250 to 500 kcmil
Conductor Type : Aluminum/Copper
Dimensions : 3-3/4 in H x 2-29/32 in W
Finish : Tin Plated
Material : Copper
Specifications : 55 ft-lb Torque, 290 A Copper, 230 A Aluminum
Temperature Rating : 90 deg C
Type : Type IPC Dual Rated
Voltage Rating : 600 V AC
  • pdf Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/ILSCO_IPC-500-250_Specification_Sheet.pdf
