ILSCO® CLND-1/0-12-134

ILSCO® SureCrimp® CLND-1/0-12-134 CLND 2-Hole Lug Compression Connector, 6 to 1/0 AWG Flex Copper Conductor, Die Code: ILD-42, 1/2 in Stud, Tin Plated Copper

  • Manufacturers: ECM Industries
  • MFR Part #: CLND-1/0-12-134
  • Revere Part #: 724378
  • UPC: 783669636826
  • UNSPSC: 39121448
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading Branch Available

ILSCO® SureCrimp® Lug Compression Connector, 2-Hole, Series: CLND, Flex Copper Conductor, 6 to 1/0 AWG Conductor, Die Code: ILD-42, 600 to 35 kV V AC, 1/2 in Stud, 3 in L x 0.738 in W x 0.125 in THK Tongue, 4.856 in Overall Length, Chamfered/Long Barrel, 0.39 in ID x 0.515 in OD x 1.5 in L Barrel, 1-3/4 in Mounting Hole Spacing, 1.562 in L Wire Strip, 90 deg C, 0.562 in Mounting Hole, Tin Plated Copper, Pink, 0.738 in W

Barrel Size : 0.39 in ID x 0.515 in OD x 1.5 in L
Barrel Type : Chamfered/Long
Color : Pink
Conductor Size : 6 to 1/0 AWG
Conductor Type : Flex Copper
Die Code : ILD-42
Dimensions : 0.738 in W
Material : Tin Plated Copper
Mounting Hole Size : 0.562 in
Overall Length : 4.856 in
Series : CLND
Specifications : 1-3/4 in Mounting Hole Spacing, 1.562 in L Wire Strip
Stud Size : 1/2 in
Temperature Rating : 90 deg C
Tongue Size : 3 in L x 0.738 in W x 0.125 in THK
Type : 2-Hole
Voltage Rating : 600 to 35 kV V AC
  • pdf Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/ILSCO_CLND-1_0-12-134_Specification_Sheet.pdf
