ILSCO® CLWD-500-12-134

ILSCO® SureCrimp® CLWD-500-12-134 CLWD 2-Hole Lug Compression Connector Sight Hole With Sight Hole, 250 to 500 kcmil Flex Copper Conductor, Die Code: ILD-87, 1/2 in Stud, Tin Plated Copper

  • Manufacturers: ECM Industries
  • MFR Part #: CLWD-500-12-134
  • Revere Part #: 744174
  • UPC: 783669646191
  • UNSPSC: 39121448
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading Branch Available

ILSCO® SureCrimp® Lug Compression Connector Sight Hole, 2-Hole, Series: CLWD, Flex Copper Conductor, 250 to 500 kcmil Conductor, Die Code: ILD-87, 600 to 35 kV V AC, 1/2 in Stud, 3 in L x 1.535 in W x 0.234 in THK Tongue, 5.982 in Overall Length, Chamfered/Long Barrel, 0.828 in ID x 1.062 in OD x 2.25 in L Barrel, 1-3/4 in Mounting Hole Spacing, 2.312 in L Wire Strip, 90 deg C, 0.562 in Mounting Hole, Tin Plated Copper, Brown, 1.535 in W

Barrel Size : 0.828 in ID x 1.062 in OD x 2.25 in L
Barrel Type : Chamfered/Long
Color : Brown
Conductor Size : 250 to 500 kcmil
Conductor Type : Flex Copper
Die Code : ILD-87
Dimensions : 1.535 in W
Material : Tin Plated Copper
Mounting Hole Size : 0.562 in
Overall Length : 5.982 in
Series : CLWD
Specifications : 1-3/4 in Mounting Hole Spacing, 2.312 in L Wire Strip
Stud Size : 1/2 in
Temperature Rating : 90 deg C
Tongue Size : 3 in L x 1.535 in W x 0.234 in THK
Type : 2-Hole
Voltage Rating : 600 to 35 kV V AC
  • pdf Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/ILSCO_CLWD-500-12-134_Specification_Sheet.pdf
