Panduit® GCE250-1/0

Panduit® StructuredGround® GCE250-1/0 Type GCE High Conductivity E-Tap Grounding Connector, 1/0 AWG Stranded to 250 kcmil, 6 AWG Solid to 1/0 AWG Stranded Max Run/Tap, 1/2 to 5/8 in Rod, Copper

  • Manufacturers: Panduit
  • MFR Part #: GCE250-1/0
  • Revere Part #: 818298
  • UPC: 074983009558
  • UNSPSC: 39121405
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading Branch Available

Panduit® StructuredGround® E-Tap Grounding Connector, Type GCE High Conductivity, 1/0 AWG Stranded to 250 kcmil, 6 AWG Solid to 1/0 AWG Stranded Maximum Run/Tap, 1/2 to 5/8 in Rod, Copper, Black, 1 in L x 1.05 in W x 2.18 in H Dimensions

Color : Black
Dimensions : 1 in L x 1.05 in W x 2.18 in H
Material : Copper
Maximum Run/Tap : 1/0 AWG Stranded to 250 kcmil, 6 AWG Solid to 1/0 AWG Stranded
Rod Size : 1/2 to 5/8 in
Type : Type GCE High Conductivity
  • pdf Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Panduit_GCC6X6250-1_0_Installation_Manual.pdf
  • pdf Technical Bulletin https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Panduit_GCC6X6250-1_0_Technical_Bulletin.pdf
  • link VIDEO LINK https://www.panduit.com/content/dam/panduit/en/products/media/4/24/624/5624/78215624.wmv
