ILSCO® CSWD-3/0-38-1

ILSCO® SureCrimp® CSWD-3/0-38-1 CSWD 2-Hole Lug Compression Connector With Sight Hole, 3/0 AWG Copper Conductor, Die Code: I-50, 3/8 in Stud

  • Manufacturers: ECM Industries
  • MFR Part #: CSWD-3/0-38-1
  • Revere Part #: 844304
  • UPC: 783669639179
  • UNSPSC: 39121448
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading Branch Available

ILSCO® SureCrimp® Lug Compression Connector, 2-Hole, Series: CSWD, Copper Conductor, 3/0 AWG Conductor, Die Code: I-50, 600 V AC, 3/8 in Stud, 1.937 in L x 0.885 in W x 0.125 in THK Tongue, 3.126 in Overall Length, Chamfered/Short/Standard Barrel, 0.484 in ID x 0.609 in OD x 0.75 in L Barrel, 1 in Mounting Hole Spacing, 0.8120 in L Wire Strip, 90 deg C, 0.406 in Mounting Hole, Orange, 0.885 in W

Barrel Size : 0.484 in ID x 0.609 in OD x 0.75 in L
Barrel Type : Chamfered/Short/Standard
Color : Orange
Conductor Size : 3/0 AWG
Conductor Type : Copper
Die Code : I-50
Dimensions : 0.885 in W
Mounting Hole Size : 0.406 in
Overall Length : 3.126 in
Series : CSWD
Specifications : 1 in Mounting Hole Spacing, 0.8120 in L Wire Strip
Stud Size : 3/8 in
Temperature Rating : 90 deg C
Tongue Size : 1.937 in L x 0.885 in W x 0.125 in THK
Type : 2-Hole
Voltage Rating : 600 V AC
  • pdf Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/ILSCO_CSWD-3_0-38-1_Specification_Sheet.pdf
