Color-Keyed® 60144
Color-Keyed® 60144 1-Hole Non-Insulated Compression Lug, 3/0 AWG Aluminum/Copper Conductor, Die Code: 60, 1/2 in Stud, Aluminum
- Manufacturers: ABB
- MFR Part #: 60144
- Revere Part #: 786581
- UPC: 786210601441
- UNSPSC: 39121405
- Replacement Part #: 7TAH007610R0035
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
-
Price: Login For Price
The Color-Keyed® compression system ensures a proper crimp onto the conductor by matching the right connector to the right tool and die, using a color coding system that was developed and introduced to the industry by T&B®. When using the Color-Keyed® compression system with our Blackburn® line of compression connectors, the installer can count on a reliable, high quality connection.
Color-Keyed® Compression Lug, 1-Hole Non-Insulated, Aluminum/Copper Conductor, 3/0 AWG Conductor, Die Code: 60, 35 kV, 1/2 in Stud, Straight Tongue, 1.41 in L x 1.06 in W x 0.22 in THK Tongue, 3.15 in Overall Length, Blind End/Long Barrel, 0.77 in Dia Barrel, Specifications: Tin Plated, 90 deg C, Aluminum, Ruby
| Barrel Size | : | 0.77 in Dia |
| Barrel Type | : | Blind End/Long |
| Color | : | Ruby |
| Conductor Size | : | 3/0 AWG |
| Conductor Type | : | Aluminum/Copper |
| Die Code | : | 60 |
| Material | : | Aluminum |
| Overall Length | : | 3.15 in |
| Specifications | : | Tin Plated |
| Stud Size | : | 1/2 in |
| Temperature Rating | : | 90 deg C |
| Tongue Size | : | 1.41 in L x 1.06 in W x 0.22 in THK |
| Tongue Type | : | Straight |
| Type | : | 1-Hole Non-Insulated |
| Voltage Rating | : | 35 kV |
Instruction/Installation Manual
